Near real-time replenishment in Dynamics 365 F&O

There is a lot of good stuff on the horizon for Dynamics 365. I highly recommend that you check out the following article of some new planning services that will come in the April 2019 release.

https://docs.microsoft.com/en-gb/business-applications-release-notes/April19/dynamics365-finance-operations/planning-service

To make this happen, I would expect the planning to go deeper into the SQL stack, and also to maximize the utilization of in-memory processing of the transactions.

For Retailers, this will be highly appreciated, where limited space in the stores means that shelf replenishment several times each day is common. Especially for perishable products with limited shelf-time. Keeping things fresh and presentable is a necessity for the customer to buy. The ability to more quickly react to customer demands ensures that the customers actually find the products in your store. And the same aspect, when there are a slower sale, the ability to adjust down the replenishment according to activity. This saves cost and increases profit. In Retail, it is the small improvements that in sum creates the big results.

For the planning service to work, it needs the transactions to take action on. In Dynamics 365 for Retail we must choose between the ability to aggregate the transactions coming from the POS/Channel databases, or more quickly posting the statements. I’m looking forward to many good discussions on this area.

The future is faster

Retail Enterprise Architecture mapping using ArchiMate and ARDOQ

The warning; The blog post is High Level, but the benefits can be mind-blowing.

Enterprise Architecture is about understanding and change. In today’s business, change is everywhere and the essential part to survive. But change is not easy. To have insights and understanding of your own organization is essential for change and risk assessment. Understanding how people, processes and technology are connected will give focus to achieve high value benefits. In my profession we use the Microsoft Dynamics technology stack as a main driver for implementing improvements. But we also acknowledge that Dynamics 365 is not the only system at work. Even though Dynamics 365 is a central component, there always will be many other systems, processes and technologies that is included in the enterprise architecture (EA). We need a way to describe all these connections in uniformed way, that allows us to communicate a model for enterprises dynamically.

But why should EA mapping be a central part of your business? here are 6 business motivators and benefits of having a structured approach of the EA mapping:

Increased stability and availability. It is critical vital that all central systems have a near 100% availability. POS and back-end systems must always work, and the supporting processes must be streamlined to secure that risks related to business improvements and changes are minimized and understood. The EA mapping documents the relationships and show consequences changes.
Guaranteed Performance. Having acceptable system response 24/7, that can deal with business pikes must be planned and built around the system. Systems must deal with a variable load, handling that the sudden event changes the transaction volume. Any disruptions quickly result in customers walking away. The EA mapping must document components central for performance compliance, and the business actors involved
Scalable capacity. New stores or changes in the business model can quickly change the requirement for transaction and processing capacity. To be cost effective, the capacity scalability must dynamic according to the actual need. Both in terms to scaling up and down. The EA mapping documents components central for scalability, and the business actors involved.
Strong security. Cyberattacks are increasing and it is vital important to secure information and transactions. Being GDPR compliant puts demands on systems and internal processes on how to handle own and customer information. Security, tractability and audit trail builds trust into the system and documenting compliancy. The EA mapping documents governance and role compliance, and the business actors involved.
Right focus. There are always new business opportunities and process improvements. Keeping track on where to focus will lead to better and faster implementation of changes in a secure and stable manner. New ideas must be analyzed, and risk assessed, and also to understand the implications. The EA mapping can assist in focusing on what changes have the highest priorities and benefits.
Cost control. Being a retailer involves large investments in technology like POS, Mobile apps, customer portals and enterprise systems. Moreover, there may be large fluctuations in system usage throughout the year. By purchasing these features in the subscription form, it is possible to equalize the operating costs and that you only pay for what is needed. Good liquidity is archived by balancing cost full investments towards the revenue stream and securing actual return on these investments

To move forward a “language” is needed to describe an enterprise architecture model where you can visualize, plan, implement and maintain all relationships that exists today, in transitions and the final vision.

Architecture Layers using ArchiMate

The overall mapping can be modelled in 5 main layers; Here I would like to focus on the symbolism used for identifying. The notation here is ArchiMate, that is open and independent enterprise architecture modeling language to support the description, analysis and visualization of architecture within and across business domains in an unambiguous way.

Motivation Elements defines the overall drivers and goals that the enterprise have. Much of the vision is located here. The Motivation elements can also be seen as a vertical layer, in close relationship to all layers.

The Strategy layer defines the overall course of action and a mapping towards resource and business capabilities.


The Business layer defines the business processes and the services the enterprise is providing, and the here the main business processes are defined. To simply the modeling it is relevant to start with the Business Objects, Business processes, Business Roles, Business actors, Business events, Business Services and Business Rules and Logics.

The Application layer contains application services and capabilities, their interactions and application processes. Here Dynamics 365 and much of the power platform is located. To simply the modeling it is relevant to start with Data objects, Application functions and Application components.


The Technology and physical layer describes the software and hardware(physical or virtual) capabilities that are required to support the deployment of business, data, and application services; this includes IT infrastructure, middleware, networks, communications, processing, standards, etc. The underlaying structure of Microsoft Azure would typically be described here. To simply the modeling it is relevant to start with Artifacts, System Software, Technology Service, Device and Communication network.

Architecture Relationships using ArchiMate

The real beauty comes, when the relationships between architecture elements are being defined. But to do this, a set of predefined relationships needs to be defined. The most common used is the following one

If putting this together in a combined setup I get the following relationship diagram of what is relevant to document.

(*Credits to Joon for this visualization)

As seen here, the business processes are a realization of the application functions, and this clarifies how a proper Enterprise Architecture modelling is documents. With this model, we can what business actors is assigned to what Business roles. This again shows the business process assignment to the role. The Business processes are there to realize business services.

Building the Architecture model using Ardoq

The architecture relationships can be challenging to describe using tools like Visio. Often, we see that great work is done, but not used to the potential. An alternative is to use cloud based mapping tools as ardoq, that covers most aspects in documenting relationships between business processes, applications, roles, risks and transitions. This is not a commercial for this tool, but I find it great. So, I decided to try to use Ardoq to model the Contoso demo data.

Here I will focus on the Application Layer, as this is the layer where the application functionality and data are located. First, I create the application components:

Then I create the Application Functions, and I also import the Business Roles that is available in the Contoso demo dataset.

Next job is to build the relationship between the application functions(D365), business processes(vertical processes) and business roles. This will allow me to visualize and to trace dependencies across all the EA mappings. Let’s take an example looking into the responsibilities of an employee named April Mayer.

I can here see that she is related to the business roles; Accounts payable clerk and manager. If I click on the “Accounts payable clerk” I jump into the view of this business role, and I can see that it is related to the business processes of accounts payable, and an association to April Mayer.

Jumping to accounts payable allows be to see the business processes involved.

I can also visualize the entire Enterprise Architecture Map will all objects and relations,

And zoom into specific on the relations; This graph shows me that April Meyer belongs to the role “Employee”, Accounts payable manager and clear. The Accounts payable clerk is associated with the business process “Accounts payable”. The clerk role is associated with the Financial management modules in Dynamics 365.

Here is another visualization, that shows the how the business objective of “Marketing” can be achieved, and what Business roles are involved, what Business processes, Application functions and what application components are also involved.

Knowing the relation and the ability to communicate is a key to happy Enterprise Architecture mapping.

Give is a try, the result can be very powerful.

Additional information

1. A high value blogger on Enterprise Architecture is http://theenterprisingarchitect.blogspot.com/.

2. Homepage of archimate: http://pubs.opengroup.org/architecture/archimate3-doc/toc.html .

3. Homepage of ARDOQ : https://ardoq.com/ Give it a try !

MPOS – Open full (kiosk) screen mode when having dual display

For a retailer, every saved “click” is appreciated, and the ability to remove any noise appreciated.

When starting MPOS in maximum mode, you will often see that you have a title bar at the top, and the app-bar at the bottom.

In windows 10 you can also use the “tablet-mode” to get the MPOS into full screen mode.

BUT! If you have a dual display setup, it the tablet mode does not work.

If you want to remove them, there is a smart keyboard short-cut:

Shift-Windows-Enter

This will put the MPOS in full screen mode, and giving a nicer appearance without the bar’s.

Then the questions is how to make this always happen, when starting the MPOS ? This was actually not a easy task, but a colleague of me (Espen) made it possible , du using a powershell script.

The following page contains a small powershell script, that opens a UWP app in full (kiosk) screen mode:

Add this to a “start up folder”, and create a new powershell script containing ;

[Path]\StartUWPAppFullScreen.ps1
-app
Shell:Appsfolder\Microsoft.Dynamics.Retail.Pos_tfm0as0j1fqzt!App



Then create a shortcut towards this new powershell app.

How initial investigations (by Sven Erik) shows that the MPOS app ID is Microsoft.Dynamics.Retail.Pos_tfm0as0j1fqzt!App and let’s hope this ID stay’s permanent.

Then the MPOS looks nicer for the user, without noice.







Retail assortments and planned orders extensions

Microsoft have created an excellent description of this in the Assortment management doc-page. Retail assortments are essential to define what products that should be available across retail channels. Assigning a product to an assortment, will assign the product to the stores that have the assortment. This makes it possible to sell the product in the store.

But there is something missing, and that is to use assortments for replenishment and procurement. Retailers want the master planning to only suggest procurement and transfers on products that belongs to the stores assortments. You can control requirement parameters per warehouse, but there is no standard way to use the assortment to control the generation of planned orders.

This blog post is to show how to make a very small extension that allows you to make sure that only products that belongs to a stores assortment will generate planned orders. The solution I will make use of is to look into how the product lifecycle state functionality is working, and extend this with an assortment planning parameter. I have called this parameter “Is lifecycle state active for assortment procurement

What it will do, is to validate if a product is in the assortment of the store, and if it is, then the product will be requirement calculated and will generate planned orders. If the product is not in the assortment of the store, that no planned orders will be generated.

To make this happen, I needed to create 4 extensions. The three first is adding a new field on the product lifecycle form.  For an experienced developer this is easy to create, and no need to spend time on in this this blog-post.

The real fun is how to manage and control the planned order generation. This happens in in an extension to the ReqSetupDim class.  Here there is a lookup to the assortment on the product, and checks if the store have this assortment.  If not, then the masterplanning will not generate any planned orders. I therefore create an extention class and use the new method wrapping/CoC feature to add some additional code.

///
<summary>
/// Contains extension methods for the ReqSetupDim class.
/// </summary>

[ExtensionOf(classStr(ReqSetupDim))]
final class ReqSetupDim_extension
{

    ///
<summary>
    /// Validates if a product should be assortment planned
    /// </summary>

    /// The parm of the ReqSetupDim class.
    /// false if the product is not assortment planned; otherwise, return default value.
    public boolean  mustReqBeCreated(InventDim _inventDimComplete)
    {
        Boolean ret = next mustReqBeCreated(_inventDimComplete);

        if (ret)
        {
            if (inventdim.InventLocationId)
            {
                InventTable                 inventtable;
                EcoResProductLifecycleState ecoResProductLifecycleState;

                //Fetching fields from  inventtable
                select firstonly ProductLifecycleStateId, Product from  inventtable where inventtable.ItemId == this.itemId();

                //validating if the product is active for planning and that also assortment planning is enabled.
                select firstonly RecId from ecoResProductLifecycleState
                        where   ecoResProductLifecycleState.IsActiveForAssortmentPlanning == true
                            &amp;&amp;  ecoResProductLifecycleState.IsActiveForPlanning == true
                            &amp;&amp;  ecoResProductLifecycleState.StateId == inventtable.ProductLifecycleStateId;

                if(ecoResProductLifecycleState)
                {
                    RetailStoreTable                    store;
                    EcoResProduct                       product;
                    RetailAssortmentLookup              assortmentLookupInclude;
                    RetailAssortmentLookup              assortmentLookupExclude;

                    RetailAssortmentLookupChannelGroup  assortmentLookupChannelGroupInclude;
                    RetailAssortmentLookupChannelGroup  assortmentLookupChannelGroupExclude;

                    //Finding OMOperatingUnitID from the inventlocationId
                    while select firstonly OMOperatingUnitID from store
                        where store.inventlocation == inventdim.InventLocationId
                    {
                        //Check if the product is in the assortment of the store in question
                        select RecId from product
                            where product.RecId == inventtable.product
                        exists join assortmentLookupInclude
                            where   assortmentLookupInclude.ProductId == product.RecId
                                &amp;&amp;  assortmentLookupInclude.lineType == RetailAssortmentExcludeIncludeType::Include
                        exists join assortmentLookupChannelGroupInclude
                                where   assortmentLookupChannelGroupInclude.OMOperatingUnitId == store.OMOperatingUnitID
                                    &amp;&amp;  assortmentLookupChannelGroupInclude.AssortmentId == assortmentLookupInclude.AssortmentId
                        notexists join assortmentLookupExclude
                            where   assortmentLookupExclude.ProductId == product.RecId
                                &amp;&amp;  assortmentLookupExclude.lineType == RetailAssortmentExcludeIncludeType::Exclude
                        exists join assortmentLookupChannelGroupExclude
                            where   assortmentLookupChannelGroupExclude.OMOperatingUnitId == store.OMOperatingUnitID
                                &amp;&amp;  assortmentLookupChannelGroupExclude.AssortmentId == assortmentLookupExclude.AssortmentId;

                        if (!product)
                        {
                            ret = false; //The product does NOT belong to the stores assortment, and should not be planned
                        }
                    }
                }
            }
        }
        return ret;
    }
}

I also have code to restrict creation of manual purchase orders, and where simular code can be used, but let’s hope that Microsoft can further extend standard Dynamics 365 with assortment based procurement planning.

Copy with pride, and let’s hope next year will give us 365 more opertunities.

POS Invoice Pay – #Dyn365F&O

A very nice omnichannel capability made available in Dynamics 365 version 8.1, is the ability for customers to pay their invoices directly in the POS. A scenario is that a customer is allowed to purchase “on-account” and then later pay all the invoices. Let’s say that the customer is in a hotel, and allows the customers to buy food, drinks and services throughout the stay. At the end of the stay the customer pays for all the services at the reception. Like “pay-before-your-leave”.

There is no requirement that the goods have to be sold on a POS. It is fully omnichannel capable. So, the orders can be created in the call-center, WEB or in stores. I would like to share this with you and how you can set it up in the Contoso demo data set. If you open the functionality profiles, you will find the possibility to enable paying:

  • Sales order invoice
  • Free text invoice
  • Project invoice (Yes! Even project invoices!)
  • Sales order credit note

The next thing you need to do is to add a “Sales invoice” – button to the transaction screen. (I’m using Houston store, and button grid F2T2)

This will add a sales invoice button to the POS design, that allows for paying invoices in POS.

The next thing is to create a POS transaction/order. First select a customer (like Karen), and then use the on-account button to sell the goods.

On the payment screen you can say how much you would like to put on account, and you also see that the credit limit and balance is available.

The next step requires that the there are some periodic batch jobs, that needs to run;

1. Run the “P-job”, to fetch the transactions from the channel database.

2. Run the “Calculate statement” (manually or in batch)

3. Run the “Post statement” (This process will create the sales order and the invoice)

!Make sure the statement is posted and invoiced before continuing!

The option you now have is to continue to the process in Dynamics 365, and create an automatic sending of the invoice to the customer through print management, or have the customer come to the “reception” and pay for the goods directly.

To pay the order, select the Karen customer, and use the Sales Invoice button.

If you have done all right, you should find the invoice in the list now. (If you have enabled aggregation in the parameters, you will have a single invoice per customer)

I can then select the invoice (or multiple), and pay it using cash, card, loyalty (And even on-account again)

This opens up for some very nice omnichannel processes, and I hope that Microsoft invests further in this. It would be nice to actually see the actual lines on the invoices that is being paid, and to even print-out the invoice if the customer requires this. Also I suggest that for retailers, use the modern report possibility to make the invoice look awesome.

Take care friends, and thanks for all your support and encouragement!

A quick look at download Retail distribution jobs (CDX)

Commerce Data Exchange (CDX) is a system that transfers data between the Dynamics 365 F&O headquarters database based and retail channels databases(RSSU/Offline database). The retail channels databases can the cloud based “default” channel database, the RSSU database and offline databases that is on the MPOS devices. If the look at the following figure from Microsoft docs, this blog post is explaining how to practically understand this.

What data is sent to the channel/offline databases?

In the retail menus you will find 2 menu items; Scheduler
jobs
and scheduler subjobs. Here the different data that can be sent is defined.

When setting up Dynamics 365 the first time, Microsoft have defined a set to ready to use scheduler jobs that get’s automatically created by the “initialize” menu item, as described here.

Scheduler jobs is a collection of the tables that should be sent, and sub jobs contains the actual mapping between D365 F&O and channel database fields. As seen in the next picture, the fields on the table CustTable in D365 is mapped towards the AX.CUSTTABLE in the channel database.

To explore what is/can be transferred, then explore the Scheduler jobs and scheduler subjobs.

Can I see what data is actually sent to the channel/offline databases?

Yes you can! In the retail menu, you should be able to find a Commerce Data Exchange, and a menu item named “Download sessions”.

Here you should see all data that is sent to the channel databases, and here there are a menu item names “Download file”.

This will download a Zip file, that contains CSV files, that corresponds to the Scheduler
jobs
and scheduler subjobs.

You can open this file in Excel to see the actual contents. (I have a few hidden columns and formatted the excel sheet to look better). So this means you can see the actual data being sent to the RSSU/Offline channel database.

All distribution jobs can be set up as batch jobs with different execution reoccurrence. If you want to make it simple but execute download distribution job 9999 to run every 30 minutes. If you have a more complex setup and need to better control when data is sent, then make separate distribution batch-jobs so that you can send new data to the channel databases in periods when there are less loads in the retail channels.

Too much data is sent to the channel databases/offline database and the MPOS is slow?

Retail is using change tracking, and this makes sure that only new and updated records is sent. This makes sure that amount of data is minimized. There is an important parameter, that controls how often a FULL distribution should be executed. By default it is 2 days. If you have lots of products and customers, we see that this generates very large distribution jobs with millions of records that will be distributed. By setting this to Zero, this will not happen. Very large distributions can cripple your POS’es, and your users will complain that the system is slow, or they get strange database errors. In version 8.1.3 it is expected to be changed to default to zero, meaning that full datasets will not be distributed automatically.

Change tracking seams not to be working?

As you may know, Dynamics 365 have also added the possibility to add change tracking on data entities when using BOYD. I have experienced that adjusting this affect the retail requirement for change tracking. If this happens, please use the Initialize retail scheduler to set this right again.

Missing upload transactions from your channel databases?

In some rare cases it have been experienced that there are missing transactions in D365, compared to what the POS is showing. The trick to resent all transactions is the following:

Run script: “delete crt.TableReplicationLog” in the RSSU DB. And the next P job will sync all transactions from RSSU DB (include missing ones).
